The Tiny Home That’s Built to Last

The Heirloom-X is everything you want, need and could dream of, all in a 20′ long package. It is built to last, with every component hand picked and no detail missed. This state of the art tiny home rounds off Tiny Heirlooms line-up of the Signature Series models, and can be a cozy home or an incredible travel trailer.

We personally took your feedback, reviews, and comments and put it all into the Heirloom-X. This is a true masterpiece and an Heirloom that will be passed down from generation to generation, sure to leave you and your family with a lifetime of joy and memories. We welcome you to the Heirloom-X.

  • Materials hand-chosen to last
  • Comes with a mattress for the loft, a fold-out couch / bed combo for the living room, and much more!
  • Pricing starts at $69,900 USD

Model Details

The Heirloom-X Includes:

  1. Trailer – Certified hand-built chassis with trailer brakes and highway lighting; DOT approved
  2. Framing – 2×4 dimensional lumber, CDX plywood with shed roof
  3. Moisture barrier – Zip System® Rigid Panel Weather Resistant Barrier (WRB)
  4. Exterior siding – Horizontal thermally-modified wood and cement board with channels
  5. Insulation – Closed-cell spray foam in roof and walls; rigid foam floor
  6. Inside cladding – Birch plywood with battens over seams
  7. Interior Finish – Clear polyurethane sealer
  8. Interior Trim – Birch 1×4
  9. Windows – Black vinyl
  10. Roofing – PVC Membrane; Dark Charcoal
  11. Flooring – Commercial-grade sheet vinyl; wood pattern
  12. Cabinets – KEA KUNGSBACKA, recycled flat black and white
  13. Hardware – Modern cabinet pulls; Brushed Gold finish
  14. Soft Close – Cabinet drawer slides and hinges
  15. Countertops – Solid surface; Pure White
  16. Appliances – High-end energy-efficient stainless finish; Fisher & Paykel 13.5 cubic foot refrigerator with ice, water and bottom freezer, Fisher & Paykel induction cooktop
  17. Kitchen sink/Dishwasher Combo – Fotile 3-in-one sink/dishwasher combo; stainless steel
  18. Kitchen Faucet – Faucet with pull-down head; Brushed Gold
  19. Bathroom sink – Wall-mounted porcelain sink
  20. Bathroom Faucet – Brushed Gold
  21. Shower – Stainless steel walls and ceiling with wood slatted floor
  22. Vanity mirror – Recessed LED backlit medicine cabinet
  23. Bathroom Accessories — One (1) toilet paper holder, one (1) towel bar, and one (1) robe hook
  24. Bathroom Exhaust Fan with Light – On a dedicated switch; 90-120 CFM
  25. Dual flush toilet – With toilet flange (connection by customer)
  26. One (1) Electric Wall Heater – With programmable thermostat; in living room
  27. Water Heater –19-gallon electric
  28. One (1) Freshwater Inlet
  29. One (1) Grey Water Outlet
  30. One (1) 50A 110/115V Power Inlet
  31. Smoke & CO Detectors Mounted in kitchen ceiling
  32. Lighting – LED recessed lights throughout and three (3) LED ceiling porch lights
  33. Doors – Two (2) sliding etched glass doors; one (1) exterior 5 lite panel fiberglass door
  34. Loft Bedroom – With drawer night stand, metal railing, and ladder
  35. Mattress — Queen size 10″ memory foam mattress in loft
  36. Couch – Converts to full size bed
  37. Extra Storage One (1) wardrobe closet with washer/dryer hookups
  38. Two (2) Exterior Outlets – One (1) high for Christmas lights; one (1) low by front door
  39. RVIA Certification
  40. Warranty – One (1) year Limited Manufacturer/Builder Warranty; all 3rd party warranties provided at completion
